Запчасти Komatsu PC50UD-2 МОТОР ПОВОРОТА (/)(№8-79) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-7T-00150

SWING MOTOR ASS'Y

|1

MOTOR SUB ASS'Y

1

708-7T-11211

CASE

2

708-7T-11612

CAP,END

3

708-7T-16110

VALVE

4

708-7T-16130

SPRING

5

07040-11812

PLUG

6

07002-11823

O-RING

7

708-7T-11120

GASKET

8

720-68-19610

PIN

9

01010-81060

BOLT

10

708-7T-12211

SHAFT

11

708-7T-12240

BEARING

12

708-7T-12250

BEARING

13

708-7T-05020

SPACER KIT

|13

SPACER¤ 1.6MM

|13

SPACER¤ 1.7MM

|13

SPACER¤ 1.8MM

|13

SPACER¤ 1.9MM

|13

SPACER¤ 2.0MM

|13

SPACER¤ 2.1MM

|13

SPACER¤ 2.2MM

14

708-7T-12230

SEAL,OIL

15

04065-04518

RING,SNAP

16

708-7T-13121

BLOCK,CYLINDER

17

708-7T-13250

PLATE,VALVE

18

720-68-19610

PIN

19

708-7T-13540

PIN

20

708-7T-13530

WASHER

21

708-7T-13560

SPRING

22

04065-03815

RING,SNAP

23

708-7T-13510

GUIDE,RETAINER

24

708-7T-13342

RETAINER,SHOE

25

708-7T-13611

PISTON SUB ASS'Y

26

708-7T-13421

PLATE,THRUST
