Запчасти Komatsu PC50UD-2 ОТВАЛ (ОТВАЛ) (НАКЛОНЯЕМ. МЕХАНИЧ. ANGLE) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

21X-910-0020

BLADE

|1

20U-910-0010

BLADE ASS'Y

1

BLADE

|1

BLADE

2

21X-910-2370

BRACKET,L.H. (WELDED)

|2

20U-910-1131

BRACKET,L.H. (WELDED)

3

20U-910-1141

BRACKET,R.H. (WELDED)

4

21X-910-2320

BRACKET,CENTER (WELDED)

|4

20U-910-1151

BRACKET,CENTER (WELDED)

5

20U-910-1190

BUSHING

6

21X-910-2820

EDGE

|6

20T-71-22220

EDGE

7

20U-910-1980

EDGE

8

02090-10845

BOLT

9

02290-10813

NUT

9A

01643-31445

WASHER

10

20U-910-1160

PIN

11

20S-70-31180

SPACER

12

01010-81230

BOLT

13

01643-31232

WASHER

14

20R-70-11270

SPACER¤ 1.0MM

15

20U-910-1171

PIN

16

20U-910-1360

BUSHING

17

20U-910-1370

COLLAR

18

20U-910-1280

COLLAR

19

20U-910-1290

BUSHING

20

07020-00675

FITTING,GREASE

21

20S-70-31180

SPACER

22

01010-81230

BOLT

23

01643-31232

WASHER

24

20U-910-1181

PIN

25

20S-70-31180

SPACER

26

01010-81225

BOLT

27

01643-31232

WASHER

28

20U-910-1360

BUSHING

29

20U-910-1370

COLLAR

30

07020-00675

FITTING,GREASE
