Запчасти Komatsu PC50MR-2 ЭЛЕКТРИКА (/) (С АККУМУЛЯТОР ОТКЮЧ-Е) КОМПОНЕНТЫ ДВИГАТЕЛЯ И ЭЛЕКТРИКА

1

22M-06-R2112

BATTERY CABLE (+)

2

08037-11825

GROMMET

3

04434-51912

CLAMP

4

04434-52712

CLAMP

5

07095-20418

RUBBER

6

01010-81020

BOLT

7

01643-11032

WASHER

8

01602-20619

WASHER, SPRING

9

01580-10605

NUT

10

01643-10823

WASHER

11

01580-10806

NUT

12

08034-20823

CLAMP

13

07095-20418

RUBBER

14

22M-06-R1311

WIRING HARNESS, EXTERNAL POWER PLUG LINE

15

21D-06-11820

FUSE 10A

16

21D-06-11220

ELECTRICAL SOCKET

17

37C-06-11181

BATTERY CABLE (-)

18

08038-04030

CAP

19

01010-81020

BOLT

20

01643-11032

WASHER

21

04434-51510

CLAMP

22

37C-06-11191

CABLE (-)

23

08038-04030

CAP

24

22L-09-R2U20

BOOT, BLACK

\24

22M-06-21500

RELAY BOX, ASSEMBLY

25

22M-06-21511

BRACKET

26

YM129211-77920

TIMER

27

YM119802-77200

RELAY

28

YM119650-77910

RELAY

29

01640-20610

WASHER

30

37A-09-1W059

SCREW

31

37A-09-1W060

SCREW

32

01640-20610

WASHER

33

01010-81025

BOLT

34

01643-11032

WASHER

35

37A-06-11910

BATTERY SWITCH

36

22M-06-R2710

BRACKET

37

01010-80625

BOLT

38

01640-20610

WASHER

39

37A-09-35406

NUT

40

395-93-13551

MARK PLATE, BATTERY DISCONNECTING SWITCH

41

22E-98-21140

MARK PLATE, BATTERY DISCONNECTING SWITCH
