Запчасти Komatsu PC50MR-2 ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC50MR-2 - ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ
49
42
52
44
53
41
43
38
50
25
51
35
37
31
32
37
34
31
32
34
56
31
26
32
47
34
28
37
31
32
36
34
37
39
31
32
27
28
40
48
31
36
32
34
31
32
27
34
28
36
32
31
27
29
28
35
18
37
18
37
24
14
13
23
19
13
20
12
21
12
16
17
1
5
26
7
55
54
54
9
55
22
11
10
34
34

Артикул

Название

Примечание

Количество

\0

22M-01-20300

ENGINE

1

YM129601-11700

HEAD ASSEMBLY, CYLINDER

5

YM120130-11860

GUIDE

7

YM129150-11810

GUIDE

9

YM27241-400000

PLUG

10

YM129004-11100

VALVE, INTAKE

11

YM129100-11110

VALVE, EXHAUST

12

YM129795-11120

SPRING

13

YM129795-11180

RETAINER

14

YM27310-080001

COTTER

16

YM121400-11340

SEAL

17

YM124460-11340

SEAL

18

YM129150-11370

CAP, VALVE

19

YM119802-11870

PROTECTOR, NOZZLE

20

YM119625-11880

SEAT, NOZZLE

21

YM129004-11900

RETAINER

22

YM22351-060012

PIN, SPRING

23

YM120270-54410

WASHER

24

YM26106-080352

BOLT, FLANGED

25

YM129601-11241

SHAFT, ASSEMBLY

26

YM119802-11260

SUPPORT

27

YM119802-11270

SUPPORT

28

YM129150-11280

SPRING

29

YM129601-11251

SHAFT, ASSEMBLY

31

YM129004-11650

ROCKER ARM, ASSEMBLY

32

YM129150-11230

SCREW, VALVE

34

YM129150-11750

NUT

35

YM26226-080182

STUD

36

YM26106-080252

BOLT, FLANGED

37

YM26106-080502

BOLT, FLANGED

38

YM129601-11350

HEAD COVER, ASSEMBLY

39

YM129004-03010

PLATE

40

YM129150-03070

BAFFLE

41

YM119802-03110

RETAINER

42

YM119802-03121

COVER

43

YM119802-03130

DIAPHRAGM

44

YM119802-03141

SPRING

47

YM129601-11310

PACKING

48

YM22857-500100

SCREW

49

YM22857-500100

SCREW

50

YM124160-01751

COVER, FILLER

51

YM24311-000320

O-RING

52

YM124160-11360

KNOB

53

YM24311-000120

O-RING

54

YM129900-07900

LIFTER

55

YM26106-080142

BOLT, FLANGED

56

YM977770-01212

GASKET, LIQUID

Выбрано товаров: 47
