Запчасти Komatsu PC50MR-2 ГИДРАВЛ МАСЛ. БАК (/) РАБОЧЕЕ ОБОРУДОВАНИЕ ГИДРАВЛИКА

\0

22M-60-R1002

HYDRAULIC TANK, ASSEMBLY

1

22M-60-R1113

HYDRAULIC TANK

2

209-60-R1190

PLUG

3

22M-60-21131

CASE

4

8A30-60-1111

BLOCK

5

8A30-60-1130

CYCLONE

6

01252-70625

BOLT, HEXAGON SOCKET HEAD

7

01643-30623

WASHER

8

07043-70211

PLUG

9

07000-12080

O-RING

10

01010-80620

BOLT

11

01643-10623

WASHER

12

01010-80860

BOLT

13

01643-10823

WASHER

14

201-60-62150

COVER

15

37B-09-11252

O-RING

16

01010-81025

BOLT

17

01643-11032

WASHER

18

20X-60-22140

SPRING

19

21W-60-R1170

VALVE, ASSY.

20

21W-60-41121

ELEMENT

21

37B-09-11363

O-RING

22

22M-60-21150

BRACKET

23

01010-81020

BOLT

24

01643-11032

WASHER

25

07270-60809

TUBE

26

37A-09-5M606

BAND

27

22M-60-21120

SUCTION FLANGE

28

201-60-R5240

TUBE

29

22E-60-11120

ELBOW

30

07040-12012

PLUG

31

37B-09-88012

O-RING

32

21E-60-R1101

FILTER

33

37B-09-11244

O-RING

34

01010-81020

BOLT

35

01643-11032

WASHER

36

20U-62-R2470

JOINT

37

07002-12434

O-RING

38

22L-09-R5130

PROTECTION

39

04434-53212

CLAMP
