Запчасти Komatsu PC50MR-2 СТАРТЕР ДВИГАТЕЛЬ

Схема запчастей Komatsu PC50MR-2 - СТАРТЕР ДВИГАТЕЛЬ
33
18
15
1
18
31
14
32
2
29
18
13
30
22
25
23
6
21
7
8
20
24
19
12
9
11
10
4
5
3
A
A
A
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

\0

22M-01-20300

ENGINE

1

YM129136-77011

STARTING MOTOR, ASSEMBLY

2

YM129136-77310

SWITCH ASSEMBLY, MAGNETIC

3

YM129900-77400

ARMATURE, ASSEMBLY

4

YMX2130350900

BEARING, BALL

5

YMX2114255110

BEARING, BALL

6

YM129900-77440

COIL, ASSEMBLY, FIELD

7

YM129900-77450

BRUSH (+)

8

YM171008-77450

SCREW

9

YM129900-77460

COVER

10

YM129900-77480

HOLDER ASSEMBLY, BRUSH

11

YM129900-77500

BRUSH (-)

12

YM129400-77490

SPRING

13

YM171008-77510

HOUSING, ASSEMBLY

14

YM129136-77520

HOUSING

15

YM171008-77540

LEVER, ASSEMBLY

18

YM129400-77571

COVER KIT

19

YM129900-77640

BOLT, FLANGED

20

YM171008-77650

PINION, ASSEMBLY

21

YMX2114555500

CLUTCH, ASSEMBLY

22

YMX2114955020

BEARING, BALL

23

YMX2240410100

BEARING, BALL

24

YM171008-77660

PINION AND SHAFT, ASSEMBLY

25

YM171008-77670

STOPPER

29

YM26106-060322

BOLT, FLANGED

30

YM26106-060402

BOLT, FLANGED

31

YM171008-77750

COVER

32

YM26116-120252

BOLT

33

YM129012-77920

COVER
