Запчасти Komatsu PC50MR-2 СИСТЕМА ОХЛАЖДЕНИЯ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC50MR-2 - СИСТЕМА ОХЛАЖДЕНИЯ ДВИГАТЕЛЬ
42
30
41
17
40
28
41
30
18
26
27
15
24
16
25
13
13
1
12
8
14
29
23
11
4
37
3
35
36
10
37
10
19
22
38
34
32
33
34
31
21
20
39
A
B
C

Артикул

Название

Примечание

Количество

\0

22M-01-20300

ENGINE

1

YM129004-42001

WATER PUMP, ASSEMBLY

3

YM129100-42051

GASKET

4

YM129100-42121

PLATE

8

YM26577-060142

SCREW

10

YM119802-49113

JOINT

11

YM23876-010000

PLUG, TAPERED

12

YM23876-020000

PLUG, TAPERED

13

YM129916-49740

PLUG

14

YM129486-42021

GASKET

15

YM129004-42040

JOINT

16

YM129486-42140

O-RING

17

YM124395-49840

GASKET

18

YM26106-080162

BOLT, FLANGED

19

YM26106-080602

BOLT, FLANGED

20

YM129403-42380

PULLEY, D=110MM

21

YM129612-42380

V-BELT

22

YM129436-44740

FAN

23

YM26106-080122

BOLT, FLANGED

24

YM129155-49801

THERMOSTAT

25

YM129150-49811

GASKET

26

YM129350-49530

COVER

27

YM129795-49551

GASKET

28

YM26106-080222

BOLT, FLANGED

29

YM23414-080000

GASKET

30

YM160769-01690

PLUG

31

YM129004-49610

PIPE, ASSEMBLY

32

YM129004-49711

PIPE

33

YM119802-49730

CLAMP

34

YM124722-59050

CLAMP

35

YM129004-49620

PIPE, ASSEMBLY

36

YM129004-49721

PIPE

37

YM124722-59050

CLAMP

38

YM119256-44760

SPACER

39

YM26106-060602

BOLT, FLANGED

40

YM26106-080452

BOLT, FLANGED

41

YM22190-160000

SEAL, WASHER

42

YM129150-49360

GASKET

Выбрано товаров: 38
