Запчасти Komatsu PC50MR-2 КАБИНА (РЫЧАГ УПРАВЛЕНИЯ ОТВАЛОМ И ТРУБЫ ДЛЯ ПОВОРОТА) (ДЛЯ ОТВ. С ИЗМ. УГЛОМ) (С КОНДИЦ.)(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

22F-54-23120

LEVER

2

203-43-44360

KNOB

3

01245-01030

SCREW

4

01641-51016

WASHER

5

22M-910-2710

BRACKET

6

01010-D1025

BOLT

7

01643-71032

WASHER

8

702-16-03410

PILOT VALVE,(SEE FIG.Y1670-21A4)

9

01245-00820

SCREW

10

01643-70823

WASHER

11

11Y-62-12130

NIPPLE

12

07000-12011

O-RING

13

02896-11008

O-RING

14

203-62-57730

BOLT

15

07000-12018

O-RING

16

702-16-53240

PLUG

17

04434-53411

CLIP

18

01010-D1020

BOLT

19

01643-71032

WASHER

20

22M-910-2740

COVER

21

22M-910-2750

SEAL

22

01245-00816

SCREW

23

01643-70823

WASHER

24

22M-910-2780

HOSE, 950MM,BLUE, WHITE

24

21U-62-34750

BAND, BLUE

24

21U-62-34770

BAND, WHITE

25

22M-910-2790

HOSE, 1100MM,GREEN, RED

25

21U-62-34730

BAND, GREEN

25

21U-62-34760

BAND, RED

26

22M-910-2840

HOSE, 2000MM,RED, YELLOW

26

20U-62-22190

O-RING

26

21U-62-34760

BAND, RED

26

21U-62-34710

BAND, YELLOW

27

22M-910-2840

HOSE, 2000MM,BLUE, YELLOW

27

20U-62-22190

O-RING

27

21U-62-34750

BAND, BLUE

27

21U-62-34710

BAND, YELLOW

28

22M-910-2840

HOSE, 2000MM,BLUE, GREEN

28

20U-62-22190

O-RING

28

21U-62-34750

BAND, BLUE

28

21U-62-34730

BAND, GREEN

29

22M-910-2840

HOSE, 2000MM,RED, RED

29

20U-62-22190

O-RING

29

21U-62-34760

BAND, RED

30

08034-20519

BAND

31

208-43-51610

BOOT
