Запчасти Komatsu PC50MR-2 ОСНОВН. КЛАПАН (9-КЛАПАН) (7/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$8

723-19-12503

CONTROL VALVE,(50L/MIN)

|$9

723-19-12502

CONTROL VALVE,(50L/MIN)

|$10

723-19-12501

CONTROL VALVE,(50L/MIN)

|$11

723-19-12901

CONTROL VALVE,(70L/MIN) (NORTH AMERICA)

|$12

723-19-12900

CONTROL VALVE,(70L/MIN) (NORTH AMERICA)

|$13

723-19-13301

CONTROL VALVE,(70L/MIN) (AUSTRALIA)

|$14

723-19-13300

CONTROL VALVE,(70L/MIN) (AUSTRALIA)

|$15

723-19-12801

CONTROL VALVE,(70L/MIN) (EU)

|$17

723-11-01650

VALVE SUB ASS'Y

1

BLOCK,VALVE

2

PLATE

3

01252-60420

BOLT

4

07000-11004

O-RING

5

723-11-19130

O-RING

6

702-21-55430

O-RING

7

VALVE

8

723-11-19922

SPRING

9

708-7R-11220

PLUG

10

07002-11223

O-RING

11

SEAL

|$29

723-11-01590

VALVE SUB ASS'Y

12

PISTON

13

SLEEVE

14

SPRING

15

07000-11010

O-RING

16

07001-01010

RING

17

07000-12012

O-RING

18

07001-02012

RING

19

723-30-51130

ORIFICE

20

723-11-19970

O-RING

21

07000-11004

O-RING

22

722-12-18240

O-RING

23

01010-80665

BOLT

24

01643-30623

WASHER
