Запчасти Komatsu PC50FR-2 ЦИЛИНДР КОВША (ВНУТР. ЧАСТИ) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

YM172976-72100

CYLINDER ASS'Y,BUCKET

2

YM172976-72110

TUBE ASS'Y,BUCKET

3

YM172165-72320

BUSHING

4

YM172168-81410

SEAL,DUST

5

YM172176-72650

ROD,BUCKET

6

YM172151-72670

BUSHING

7

YM172168-81410

SEAL,DUST

8

YM172976-72150

HEAD

9

YM172151-72540

BUSHING,ROD

11

YM172976-72360

PISTON KIT,BUCKET

12

YM172312-72730

SEAL SET,HEAD

17

YM933111-26700

RING,SNAP

18

YM172142-72260

WASHER

19

YM172142-72950

SEAL SET,PISTON

22

YM172148-72081

PISTON

23

YM933111-20200

U-NUT

24

YM24761-040000

FITTING,GREASE

25

YM172976-72130

TUBE

26

YM26013-100202

BOLT

27

YM194145-04810

WASHER

28

YM172312-72290

SPACER
