Запчасти Komatsu PC50FR-2 ТОПЛИВН. БАК. AND ТОПЛИВН. ЛИНИЯ ТОПЛИВН. БАК. AND КОМПОНЕНТЫ

1

YM772964-14101

TANK ASS'Y,FUEL

2

YM104200-11920

COCK

4

YM172164-14171

HOSE

5

YM172162-14180

GAUGE UNIT,FUEL

6

YM172162-14200

PACKING

7

YM172141-14260

FLOAT

8

YM172964-14301

CAP,FUEL TANK

9

YM172122-14350

GASKET

10

YM172183-14250

STRAINER

11

YM22217-050000

WASHER,SPRING

12

YM23010-014000

BAND

13

YM26557-050122

SCREW

14

YM23080-013000

CLAMP,HOSE

15

YM22217-140000

WASHER

16

YM22137-140000

WASHER

17

YM26116-140352

BOLT

18

YM172171-14300

CLAMP

19

YM172116-14620

HOSE,FUEL

20

YM172164-14620

HOSE

21

YM172176-14620

HOSE

22

YM129335-55700

WATER SEPARATOR A.

23

YM104200-55321

VALVE,TAPER

24

YM104200-55330

SPRING,VALVE

25

YM104200-55341

LEVER,COCK

26

YM124064-55510

CASE,FUEL STRAINER

27

YM102103-55520

O-RING

28

YM110250-55610

RING,RETAINING

29

YM121257-55720

SPRING,SCREEN

30

YM121257-55731

FLOAT

32

YM101720-55750

PLUG

33

YM104200-55750

SCREW

34

YM171081-55910

SCREEN

35

YM23418-060000

GASKET,NYLON

36

YM24311-240100

O-RING

37

YM124766-59050

CLAMP

38

YM22217-080000

WASHER,SPRING

39

YM26116-080702

BOLT

40

YM933152-09280

BAND
