Запчасти Komatsu PC490LC-11 ВПУСК ВОЗДУХА БЛОК, KOMATSU ЗАКРЫТ.D CRANKКОРПУС ВЕНТИЛЯТОРILATION (KCCV) (№8-) ВПУСК ВОЗДУХА БЛОК

1

600-332-1411

Ventilator

1

600-331-1900

Element Kit

2

6751-81-5190

Joint

3

07206-30812

Bolt, Joint

4

07005-01212

Seal, Washer

5

01010-81070

Bolt

6

01643-31032

Washer

7

6252-21-7180

Hose

8

07281-00359

Clamp, Hose

9

6252-21-7630

Hose

10

07281-00359

Clamp, Hose

11

6252-21-7730

Hose

12

6252-21-7520

Hose

13

6252-21-7510

Hose

14

6252-21-7290

Gasket

15

6252-21-7280

Connector

16

600-051-2160

Clip

17

07281-00197

Clamp

18

01010-81030

Bolt

19

01643-31032

Washer

20

01010-81020

Bolt

21

01643-31032

Washer

22

7700-45-1710

Bolt, Joint

23

6261-51-2810

Valve, Check

24

6252-21-7470

Joint

25

6151-51-8490

Spacer

26

600-051-2160

Clip

27

07281-00197

Clamp

28

208-01-21690

Hose

29

6252-21-7660

Hose

30

07005-01412

Seal, Washer

31

01010-81025

Bolt

32

01643-31032

Washer

33

6252-21-7710

Tube

34

01010-81030

Bolt

35

01643-31032

Washer

36

6252-11-2900

Sensor

37

6252-11-2800

O-ring

38

600-331-1930

Bolt

39

01640-20508

Washer

40

6252-21-7670

Hose

41

07281-00359

Clamp, Hose

42

6252-21-7720

Hose

43

07281-00197

Clamp

44

208-01-21670

Bracket

45

01010-81230

Bolt

46

01643-31232

Washer
