Запчасти Komatsu PC490LC-11 СИСТЕМА ОХЛАЖДЕНИЯ, РЕЗЕРВН. БАК ТРУБЫ (№8-) СИСТЕМА ОХЛАЖДЕНИЯ

1

208-03-41441

Hose

2

207-01-75340

Clamp

3

208-03-41451

Hose

4

207-01-75340

Clamp

5

208-03-41470

Tube

6

208-03-21490

Bracket

7

07283-37663

Clip

8

01597-01009

Nut

9

01643-31032

Washer

10

01010-81230

Bolt

11

01643-31232

Washer

|$11

208-03-21662

Cover

12

Plate

13

208-03-21691

Seal

14

208-03-41671

Seal

15

208-03-41681

Seal

16

208-03-41710

Seal

17

01010-81230

Bolt

18

01643-31232

Washer

19

208-03-41721

Cover

20

208-03-41731

Seal

21

208-03-41741

Seal

22

01010-81230

Bolt

23

01643-31232

Washer

24

208-03-41751

Cover

25

208-03-41761

Seal

26

01010-81230

Bolt

27

01643-31232

Washer

28

208-03-41770

Cover

29

208-03-41780

Seal

30

01010-81230

Bolt

31

01643-31232

Washer

32

20Y-03-42340

Hose

33

206-03-43340

Clip

34

04434-51212

Clip

35

208-03-21510

Bracket

36

01010-81240

Bolt

37

01643-31232

Washer

38

208-03-42350

Hose Assembly
