Запчасти Komatsu PC490LC-11 МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА, МОТОР ХОДА, ПРАВ. (/) (№8-) МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

208-27-00510

Final Drive Assembly

|$1

706-8J-01430

Motor Assembly

1

Case, Motor

|$3

706-8J-00650

Cover Subassembly

2

Cover, End

3

Plate

4

Cylinder Block

5

Spool

6

Plug, Stocking

7

706-86-71310

Pin

8

706-8E-14191

Plug

9

07002-11823

O-ring

10

706-8J-71550

Piston

11

706-8J-71560

Pin

12

706-8J-71130

Plug

13

07002-12434

O-ring

14

706-8J-71140

Plug

15

07002-12434

O-ring

16

20B-27-11210

Bleeder

17

706-75-74540

Valve

18

706-75-74550

Spring

19

706-75-74850

Plug

20

07002-13334

O-ring

21

708-8F-36120

Ring

22

706-78-71280

Spring

23

706-78-71230

Plug

24

07002-13634

O-ring

25

706-8E-14170

Spring

26

706-8J-71150

Spool

27

706-8J-71160

Plug

28

07002-11823

O-ring

29

708-3D-15110

Valve

30

706-8J-72190

Plug

31

07002-11023

O-ring

32

706-8J-71181

Valve

33

706-8J-71190

Plug

34

07002-11223

O-ring

35

706-8J-72330

Spring

36

07000-15275

O-ring

37

07000-12012

O-ring

38

01252-62060

Bolt, Hexagon Socket Head
