Запчасти Komatsu PC490LC-11 КАПОТ, ЦЕНТР. (/) (№8-8) КАПОТ

1

208-54-21411

Frame

2

20Y-54-28161

Hinge, Welded

3

205-54-76260

Catcher

3

205-54-76280

Rotor Assembly

4

01010-80820

Bolt

5

01643-30823

Washer

6

208-54-23521

Cover

7

01010-81230

Bolt

8

01643-31232

Washer

9

206-54-21682

Bracket

10

01010-81230

Bolt

11

01643-31232

Washer

12

208-54-44350

Cover

13

01010-81230

Bolt

14

01643-31232

Washer

15

208-54-23860

Bracket

16

01010-81230

Bolt

17

01643-31232

Washer

17

208-54-23810

Cover Assembly

18

Cover

|$20

20Y-54-71460

Stud, Welded

19

124-A62-1920

Cap

20

208-54-41260

Sheet

21

208-54-43681

Sheet

22

208-54-43810

Sheet

23

01010-81230

Bolt

24

01643-31232

Washer

25

205-54-67660

Support

26

01010-80825

Bolt

27

01643-30823

Washer

28

208-54-43741

Cover

|$31

20Y-54-71460

Stud, Welded

29

208-54-43751

Sheet

30

124-A62-1920

Cap

31

01010-81220

Bolt

32

01643-31232

Washer

33

208-54-43721

Cover

34

01010-81220

Bolt

35

01643-31232

Washer
