Запчасти Komatsu PC490LC-11 СОЛЕНОИДНЫЙ КЛАПАН, ВНУТР. ЧАСТИ, СОЛЕНОИДНЫЙ КЛАПАН (№8-) СОЛЕНОИДНЫЙ КЛАПАН, -ДОПОЛН. АКТУАТОР ТРУБЫ, АККУМУЛЯТОР

|$0

207-60-71320

Valve Assembly

1

Block

2

20Y-60-32121

Solenoid Assembly

3

07000-12016

O-ring

4

07000-12011

O-ring

5

NY07207-11700

Tube

6

NY07529-10200

Tube

7

NY07529-10300

Tube

8

NY07529-10400

Tube

9

NY07529-10500

Tube

10

NY07529-10600

Tube

11

NY07505-10200

Tube

12

NY07880-10900

Tube

13

NY89103-00199

Band, Black

14

NY89103-00089

Band, Blue

15

NY89103-00091

Band, Red

16

NY89103-00183

Band, Yellow

17

NY89103-00092

Band, Green

18

NY89103-00144

Band, Brown

19

NY89103-00090

Band, White

20

NY89103-00139

Band, Pink

21

NY05062-1170A

Plunger

22

NY05062-11800

Spring

23

07000-11010

O-ring

24

NY06277-1320A

Plug

25

NY80000-02200

Plug

26

NY16207-10200

Sleeve

27

NY06339-10200

Spring

28

NY07493-10200

Spool

29

NY16207-10300

Spool

30

NY81446-05012

Bolt

31

NY09000-11400

Plate

32

NY80000-02100

Plug

33

07000-11008

O-ring

34

NY84110-00248

Screw
