Запчасти Komatsu PC490LC-11 ПОРШЕНЬ НАСОС, ВНУТР. ЧАСТИ (/7) (№8-) ПОРШЕНЬ НАСОС

|$0

708-2J-00012

Pump Assembly

|$1

708-2J-01012

Pump Subassembly

1

708-2J-12150

Coupling

2

708-2J-13530

Bearing, Thrust

3

708-2H-32320

Bushing

4

708-2J-13361

Impeller

5

01252-91650

Bolt, Hexagon Socket Head

6

04020-00820

Pin, Dowel

7

708-2J-11140

Cover

8

07000-A2105

O-ring

9

708-2H-05120

Shim Kit

9

Shim, T=0.1mm

9

Shim, T=0.2mm

9

Shim, T=0.5mm

10

01010-81235

Bolt

11

01643-31232

Washer

|$16

708-2J-04210

Case Assembly

12

708-2J-12530

Case

13

708-2J-12540

Collar

14

708-2J-12510

Shaft

15

708-8H-22350

Bearing

16

708-2J-12520

Bearing

17

708-2J-05130

Spacer Kit

17

Spacer, T=1.6mm

17

Spacer, T=1.7mm

17

Spacer, T=1.8mm

17

Spacer, T=1.9mm

17

Spacer, T=2.0mm

17

Spacer, T=2.1mm

17

Spacer, T=3.15mm

17

Spacer, T=3.65mm

17

Spacer, T=4.15mm

18

04064-04018

Ring, Snap

19

708-2J-05120

Shim Kit

19

Shim, T=0.1mm

19

Shim, T=0.2mm

19

Shim, T=0.5mm

19

Shim, T=1.0mm

20

04065-01030

Ring, Snap

21

708-2J-13540

Spacer

22

01010-E1220

Bolt

23

708-2H-32350

Washer

|$42

708-2J-05220

Gear Kit

24

708-2J-13510

Gear, Bevel

25

708-2J-13520

Pinion

26

708-2J-13550

Pinion
