Запчасти Komatsu PC490LC-11 ВЫПУСКН., ТРУБКА И КОРПУС (№8-8) ВЫПУСКН.

1

208-01-21511

Tube

2

6211-11-5490

Gasket

3

01020-11245

Bolt, Stainless

4

208-01-21630

Bracket

5

01643-31232

Washer

6

208-01-21531

Tube

7

208-01-21541

Tube

8

6211-11-5490

Gasket

9

01020-11245

Bolt, Stainless

10

208-01-21630

Bracket

11

01643-31232

Washer

12

22B-46-24380

Washer

13

6534-91-1120

Clamp

14

6534-91-1130

Gasket

15

208-01-21551

Bracket

16

01010-81240

Bolt

17

20Y-54-12670

Washer

18

07283-31087

Clip, Pipe

19

198-03-75870

Seat

20

01597-01211

Nut

21

01643-31232

Washer

22

208-01-21571

Bracket

23

208-01-21561

Bracket

24

01010-81230

Bolt

25

175-54-34170

Washer

26

6252-11-5910

Plug
