Запчасти Komatsu PC490LC-11 УПРАВЛЯЮЩ. КЛАПАН, ВНУТР. ЧАСТИ (/) (№8-) УПРАВЛЯЮЩ. КЛАПАН, 8-СЕКЦИОНН., С -ДОПОЛН. АКТУАТОР ТРУБЫ, АККУМУЛЯТОР

|$0

723-48-28401

Valve, Control

|$1

723-48-28400

Valve Assembly, Control

|$2

723-40-73500

Valve Assembly

1

Valve Body

2

Spool

3

Plug, Stocking

4

723-40-72800

Plate Assembly

5

702-21-62300

Valve, Pilot

6

700-80-61260

O-ring

7

723-11-19960

O-ring

8

702-21-54180

Screw

9

702-16-55610

O-ring

10

723-46-15111

Case

11

07430-71380

O-ring

12

723-40-71330

Retainer

13

723-40-71340

Spring

14

723-40-71350

Retainer

15

01252-60816

Bolt, Hexagon Socket Head

16

723-40-71870

Union

17

02896-11008

O-ring

18

07002-11423

O-ring

19

07040-11409

Plug

20

07002-11423

O-ring

21

01252-60855

Bolt, Hexagon Socket Head

22

01252-60635

Bolt, Hexagon Socket Head

23

Spool Assembly

24

723-40-71850

Spring

25

723-46-18720

O-ring

26

Spool

27

723-40-71390

Spring

28

723-46-18720

O-ring

28

723-40-73600

Valve Assembly

29

723-40-73700

Valve, Relief

30

702-16-53920

O-ring

31

07002-11623

O-ring

32

Block

33

Spool

34

Spring

35

702-21-55620

Plug

36

07002-11423

O-ring

37

723-40-71580

Plug

38

702-21-55720

Spring

39

04260-00793

Ball

40

07002-11023

O-ring

41

Plug, Stocking
