Запчасти Komatsu PC490LC-10 РУКОЯТЬ, 8MM, KUK, ЦИЛИНДР КОВША РУКОЯТЬ, 8MM, KUK

Схема запчастей Komatsu PC490LC-10 - РУКОЯТЬ, 8MM, KUK, ЦИЛИНДР КОВША РУКОЯТЬ, 8MM, KUK
4
7
22
22
17
18
19
36
31
31
4
25
11
12
13
14
15
16
40
20
23
21
26
23
25
24
27
28
29
32
36
35
35
10
9
8
3
6
2
5
1
7
41
39
38
33
32
37
29
30
37
30
34

Артикул

Название

Примечание

Количество

|$0

707-E1-00750

Cylinder Assembly

1

721-13-16450

Cylinder

2

721-58-11140

Rod, Piston

3

707-76-10290

Bushing

4

07145-00100

Seal, Dust, (Kit : K07)

5

07020-00000

Fitting, Grease

6

707-76-10140

Bushing

7

208-70-73530

Seal, Dust, (Kit : K07)

8

07020-00000

Fitting, Grease

9

721-27-16080

Head, Cylinder

10

707-56-11740

Seal, Dust, (Kit : K07)

11

07179-13126

Ring, Snap

12

707-52-90851

Bushing

13

707-51-11860

Packing, Rod, (Kit : K07)

14

707-51-11650

Ring, Buffer, (Kit : K07)

15

707-35-31510

Ring, Back-Up, (Kit : K07)

16

07000-B5150

O-Ring, (Kit : K07)

17

01010-82085

Bolt

18

707-88-75310

Washer

19

707-75-11040

Ring, Snap

20

707-36-16580

Piston

21

707-44-16150

Ring, Piston, (Kit : K07)

22

707-39-16120

Ring, Wear, (Kit : K07)

23

707-44-16910

Ring

24

07000-B5100

O-Ring, (Kit : K07)

25

707-35-31000

Ring, Back-Up, (Kit : K07)

26

01310-01216

Screw

27

707-86-00890

Tube

28

707-86-12570

Tube

29

07372-21060

Bolt

30

01643-51032

Washer

31

07000-13035

O-Ring, (Kit : K07)

32

707-88-25390

Bracket

33

07372-21240

Bolt

34

01643-51232

Washer

35

707-88-10150

Clamp

36

07372-21245

Bolt

37

01643-51232

Washer

38

707-88-33040

Cap

39

07371-31049

Flange, Split

40

07372-21035

Bolt

41

01643-51032

Washer

K07

707-99-72070

Seal Kit, Hydraulic Cylinder

Выбрано товаров: 43
