Запчасти Komatsu PC490LC-10 РУКОЯТЬ, 9MM, С -ДОПОЛН. АКТУАТОР ТРУБЫ, АККУМУЛЯТОР, БЫСТРОСЪЕМН. МЕХ-М, KUK, ЦИЛИНДР КОВША (ДЛЯ LC DEMO) РУКОЯТЬ, 9MM, С -ДОПОЛН. АКТУАТОР ТРУБЫ, АККУМУЛЯТОР, БЫСТРОСЪЕМН. МЕХ-М, KUK

|$1

707-H1-X0150

Cylinder Group

|$2

707-F1-00150

Cylinder Assembly

1

707-13-00150

Cylinder

2

707-76-10290

Bushing

3

07145-00100

Seal, Dust, (Kit)

4

07020-00000

Fitting, Grease

5

721-58-11120

Rod

6

707-76-10140

Bushing

7

208-70-73530

Seal, Dust, (Kit)

8

07020-00000

Fitting, Grease

9

707-27-16580

Head

10

707-56-11740

Seal, Dust, (Kit)

11

07179-13126

Ring, Snap

12

707-52-90850

Bushing

13

707-75-11040

Ring, Snap

14

707-51-11030

Packing, Rod, (Kit)

15

707-51-11650

Ring, Buffer, (Kit)

16

707-35-91640

Ring, Back-Up, (Kit)

17

07000-15150

O-Ring, (Kit)

18

707-88-81530

Bolt

19

707-88-75310

Washer

20

707-36-16580

Piston

21

01310-01216

Screw

22

707-44-16150

Ring, Piston, (Kit)

23

707-39-16120

Ring, Wear, (Kit)

24

707-44-16910

Ring

25

07001-05100

Ring, Back-Up, (Kit)

26

07000-15100

O-Ring, (Kit)

27

707-86-12580

Tube

28

707-86-12570

Tube

29

07372-21060

Bolt

30

01643-51032

Washer

31

07000-13035

O-Ring, (Kit)

32

707-88-25390

Bracket

33

07372-21240

Bolt

34

01643-51232

Washer

35

707-88-10150

Clamp

36

01010-81245

Bolt

37

01643-31232

Washer

38

707-88-33040

Cap

39

07371-31049

Flange, Split

40

07372-21035

Bolt

41

01643-51032

Washer

Kit

707-99-59760

Seal Kit, Hydraulic Cylinder
