Запчасти Komatsu PC490LC-10 C-7 ВЕНТИЛЯТОР ОХЛАЖДЕНИЯ МОТОР (/) СИСТЕМА ОХЛАЖДЕНИЯ

|$0

708-7W-00220

MOTOR ASSEMBLY

1

2907-21-6160

O-RING

2

04020-01024

PIN, DOWEL

3

01252-61480

BOLT

4

708-7W-12130

SHAFT

5

708-7W-12120

BEARING

6

708-7L-12140

BEARING

7

708-7L-05010

SPACER KIT

|$8

NSS

SPACER, T = 1.5 MM

|$9

NSS

SPACER, T = 1.6 MM

|$10

NSS

SPACER, T = 1.7 MM

|$11

NSS

SPACER, T = 1.8 MM

|$12

NSS

SPACER, T = 1.9 MM

|$13

NSS

SPACER, T = 2.0 MM

8

708-25-52861

SEAL, OIL

9

708-2L-22160

SPACER

10

04065-06825

RING, SNAP

11

708-7W-13110

CYLINDER BLOCK

12

708-8F-33230

PLATE

13

720-68-19610

PIN

14

708-8F-33360

PIN

15

708-7L-13140

SEAT

16

708-8F-33160

SPRING

17

04065-04818

RING, SNAP

18

708-8F-33350

GUIDE, RETAINER

19

708-2L-33350

RETAINER, SHOE

20

708-8F-33310

PISTON SUBASSEMBLY

21

708-7L-13410

PLATE, THRUST
