Запчасти Komatsu PC490LC-10 A- ГЕНЕРАТОР AMP ДВИГАТЕЛЬ

|$0

600-861-5110

ALTERNATOR ASSEMBLY, 50 A

1

KD0-35100-0300

ROTOR ASSEMBLY

2

KD0-35923-0160

COLLAR

3

KD1-33923-0790

COLLAR

4

KD0-09201-0980

BEARING, BALL

5

KD0-35300-0190

BRCAKET ASSEMBLY, FRONT

6

KD0-35926-0070

RETAINER

7

KD0-35926-0060

RETAINER

8

KD0-35926-0090

RETAINER

9

KD0-09201-0880

BEARING, BALL

10

KD1-33926-0730

RETAINER

11

KD0-35120-0210

COIL ASSEMBLY, FIELD

12

KD0-35200-0430

STATOR ASSEMBLY

13

KD0-0275-06802

BOLT

|$14

KD0-35700-0750

BRACKET ASSEMBLY, REAR

14

KD0-35710-0870

BRACKET, REAR

15

KD0-35730-0510

RECTIFIER ASSEMBLY

16

KD7-35719-0201

REGULATOR ASSEMBLY

17

KD1-0331-06013

WASHER

18

KD0-09120-0770

PLATE

19

KD0-35784-0240

BAR

20

KD0-35923-0130

COLLAR

21

KD0-35943-0140

BUSHING INSULATE

22

KD0-35943-0150

BUSHING INSULATE

23

KD0-35943-0160

BUSHING INSULATE

24

KD0-35943-0170

BUSHING INSULATE

25

KD0-09011-3270

SCREW

26

KD0-0055-05202

SCREW

27

KD0-0056-05302

SCREW

28

KD0-33902-0090

NUT

29

KD0-33902-0080

NUT

30

KD0-35411-0640

PULLEY

31

KD0-35421-0170

FAN

32

KD1-0335-16002

WASHER, SPRING

33

KD0-0280-16022

NUT

34

KD0-35761-0220

COVER
