Запчасти Komatsu PC490LC-10 A- КОЛЕНВАЛ ДВИГАТЕЛЬ

|$0

6252-31-1010

CRANKSHAFT

1

NSS

CRANKSHAFT

2

6150-35-1120

GEAR, CRANKSHAFT

3

6150-31-1130

KEY

|$4

6150-21-8010

MAIN METAL ASSEMBLY, STANDARD

|$5

6150-29-8010

MAIN METAL ASSEMBLY, UNDERSIZE 0.25 MM

|$6

6150-28-8010

MAIN METAL ASSEMBLY, UNDERSIZE 0.50 MM

|$7

6150-27-8010

MAIN METAL ASSEMBLY, UNDERSIZE 0.75 MM

|$8

6150-26-8010

MAIN METAL ASSEMBLY, UNDERSIZE 1.00 MM

4

NSS

METAL, STANDARD

|$10

NSS

METAL, UNDERSIZE 0.25 MM

|$11

NSS

METAL, UNDERSIZE 0.50 MM

|$12

NSS

METAL, UNDERSIZE 0.75 MM

|$13

NSS

METAL, UNDERSIZE 1.00 MM

5

NSS

METAL, STANDARD

|$15

NSS

METAL, UNDERSIZE 0.25 MM

|$16

NSS

METAL, UNDERSIZE 0.50 MM

|$17

NSS

METAL, UNDERSIZE 0.75 MM

|$18

NSS

METAL, UNDERSIZE 1.00 MM

6

6150-21-8050

METAL ASSEMBLY, STANDARD

|$20

6150-29-8050

METAL ASSEMBLY, OVERSIZE 0.25 MM

|$21

6150-28-8050

METAL ASSEMBLY, OVERSIZE 0.50 MM

|$22

6150-27-8050

METAL ASSEMBLY, OVERSIZE 0.75 MM

|$23

6150-26-8050

METAL ASSEMBLY, OVERSIZE 1.00 MM

|$24

NSS

METAL, THRUST STANDARD

|$25

NSS

METAL, THRUST OVERSIZE 0.25 MM

|$26

NSS

METAL, THRUST OVERSIZE 0.50 MM

|$27

NSS

METAL, THRUST OVERSIZE 0.75 MM

|$28

NSS

METAL, THRUST OVERSIZE 1.00 MM
