Запчасти Komatsu PC490LC-10 T- ЦИЛИНДР КОВША РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

707-E1-00750

CYLINDER

1

721-13-16450

CYLINDER

2

721-58-11140

ROD, PISTON

3

707-76-10290

BUSHING

4

07145-00100

SEAL, DUST

5

07020-00000

FITTING, GREASE

6

707-76-10140

BUSHING

7

208-70-73530

SEAL, DUST

8

07020-00000

FITTING, GREASE

9

721-27-16080

HEAD, CYLINDER

10

707-56-11740

SEAL, DUST

11

07179-13126

RING, SNAP

12

707-52-90851

BUSHING

13

707-51-11860

PACKING, ROD

14

707-51-11650

RING, BUFFER

15

707-35-31510

RING, BACK-UP

16

07000-B5150

O-RING

17

01010-82085

BOLT

18

707-88-75310

WASHER

19

707-75-11040

RING, SNAP

20

707-36-16580

PISTON

21

707-44-16150

RING, PISTON

22

707-39-16120

RING, WEAR

23

707-44-16910

RING

24

07000-B5100

O-RING

25

707-35-31000

RING, BACK-UP

26

01310-01216

SCREW

27

707-86-00890

TUBE

28

707-86-12570

TUBE

29

07372-21060

BOLT

30

01643-51032

WASHER

31

07000-13035

O-RING

32

707-88-25390

BRACKET

33

07372-21240

BOLT

34

01643-51232

WASHER

35

707-88-10150

CLAMP

36

07372-21245

BOLT

37

01643-51232

WASHER

38

707-88-33040

CAP

39

07371-31049

FLANGE, SPLIT

40

07372-21035

BOLT

41

01643-51032

WASHER

|$42

707-99-72070

SERVICE KIT, BUCKET CYLINDER
