Запчасти Komatsu PC490LC-10 M-A ЛЕВ. COVER ЧАСТИ КОРПУСА И КРЫШКИ

1

208-54-42811

FRAME

2

208-54-42821

FRAME

3

208-54-42831

FRAME

4

01010-81225

BOLT

5

01643-31232

WASHER

6

208-54-42870

PLATE

7

01010-81225

BOLT

8

01643-31232

WASHER

9

208-54-42880

BRACKET

10

01010-81225

BOLT

11

01643-31232

WASHER

12

208-54-42890

BRACKET

13

01010-81225

BOLT

14

01643-31232

WASHER

15

205-54-51971

DOVETAIL

16

01010-80616

BOLT

17

01643-30623

WASHER

18

20Y-54-11611

STOPPER

19

01580-11008

NUT

20

208-54-42841

COVER

21

20Y-54-63414

HINGE, WELDED

22

20Y-54-71372

LOCK, WELDED

23

01010-81225

BOLT

24

124-54-26540

WASHER

25

205-54-53550

DOVETAIL

26

01010-80616

BOLT

27

01643-30623

WASHER

28

20Y-54-29232

BAR

29

208-54-42941

SHEET

30

208-54-42951

SHEET

31

208-54-42970

SHEET

32

208-54-42931

SHEET

33

208-54-42961

SHEET

34

208-54-42990

SHEET

35

01010-81230

BOLT

36

01643-31232

WASHER

37

208-54-42862

COVER

38

208-54-42922

SHEET

39

208-54-43310

SHEET

40

203-54-62670

COLLAR

41

01010-81230

BOLT

42

01643-31232

WASHER
