Запчасти Komatsu PC490LC-10 M-A КАПОТ, ПРАВ. ЧАСТИ КОРПУСА И КРЫШКИ

|$0

208-54-44292

COVER ASSEMBLY

1

NSS

COVER

2

20Y-54-28161

HINGE, WELDED

3

208-54-43961

SEAL

4

208-54-43971

SEAL

5

208-54-43981

SEAL

6

208-54-43990

SEAL

7

208-54-44241

SEAL

8

208-54-44261

SEAL

9

208-54-44271

SEAL

10

208-54-44281

SEAL

11

208-54-44310

SEAL

12

208-54-44420

SEAL

13

208-54-44430

SEAL

14

01010-81250

BOLT

15

01643-31232

WASHER

16

208-54-41271

COVER

17

01010-81230

BOLT

18

01643-31232

WASHER

19

208-54-41151

LOUVER

20

01010-81230

BOLT

21

01643-31232

WASHER

22

208-54-44450

PLATE

23

01010-81230

BOLT

24

01643-31232

WASHER

|$25

208-54-43911

COVER ASSEMBLY

25

124-A62-1920

CAP

26

NSS

COVER

|$28

20Y-54-71460

STUD, WELDED

27

208-54-43861

SHEET

28

208-54-43881

SEAL

29

208-54-43891

SEAL

30

01010-81230

BOLT

31

01643-31232

WASHER

|$34

208-54-43941

COVER ASSEMBLY

32

124-A62-1920

CAP

33

208-54-43891

SEAL

34

NSS

COVER

|$38

20Y-54-71460

STUD, WELDED

35

208-54-44111

SHEET

36

208-54-44121

SHEET

37

208-54-44151

SHEET

38

208-54-44160

SHEET

39

208-54-44170

SHEET

40

208-54-44191

SHEET

41

208-54-44211

SEAL

42

208-54-44221

SEAL

43

208-54-44230

SEAL

44

01010-81230

BOLT

45

01643-31232

WASHER

46

01010-81230

BOLT

47

01643-31232

WASHER

48

208-54-43781

PLATE

49

01010-81230

BOLT

50

01643-31232

WASHER

51

208-54-43791

PLATE

52

01010-81230

BOLT

53

01643-31232

WASHER

54

209-54-77190

STAY

55

01643-31645

WASHER

56

04050-14028

PIN, COTTER

57

01010-81230

BOLT

58

175-54-34170

WASHER

59

01010-81230

BOLT

60

01643-31232

WASHER

61

208-54-43522

PLATE

62

01010-81230

BOLT

63

175-54-34170

WASHER
