Запчасти Komatsu PC490LC-10 A- КОРОМЫСЛО И КОЖУХ ДВИГАТЕЛЬ

|$0

6251-11-7300

HOUSING

|$1

6251-11-7100

HOUSING

1

6251-11-7110

HOUSING, ROCKER ARM

2

07043-30108

PLUG

3

6251-11-8830

SEAL

4

6251-11-8840

RING

5

6251-11-7220

GASKET

6

01437-01075

BOLT

7

6251-71-1170

BOLT

8

01643-31032

WASHER

|$10

6150-41-5400

ARM, INTAKE

9

NSS

ARM, ROCKER

10

6150-41-5420

BUSHING

11

6150-41-5541

SCREW

12

01582-01008

NUT

|$15

6154-41-5500

ARM, EXHAUST

13

NSS

ARM, ROCKER

14

6162-43-5340

RIVET

15

6150-41-5420

BUSHING

16

6150-41-5541

SCREW

17

01582-01008

NUT

|$21

6150-42-5300

ROCKER ARM SHAFT

18

NSS

SHAFT

19

6710-41-5340

RIVET

20

6154-41-5321

COLLAR

21

6150-81-9370

BOLT
