Запчасти Komatsu PC490LC-10 H-A ГИДР. НАСОС. (/7) ГИДРАВЛИКА

1

708-2J-12150

COUPLING

2

708-2J-13530

BEARING, THRUST

3

708-2H-32320

BUSHING

4

708-2J-13360

IMPELLER

5

01010-E1220

BOLT

6

708-2H-32350

WASHER

7

708-2H-32360

SHAFT

8

708-2J-11140

COVER

9

07000-A2105

O-RING

10

708-2H-05120

SHIM KIT

|$11

NSS

SHIM, T= 0.10 MM

|$12

NSS

SHIM, T= 0.20 MM

|$13

NSS

SHIM, T= 0.50 MM

11

01010-81235

BOLT

12

01643-31232

WASHER

|$16

708-2J-04210

CASE ASSEMBLY

13

708-2J-12530

CASE

14

708-2J-12540

COLLAR

15

708-2J-12510

SHAFT

16

708-8H-22350

BEARING

17

708-2J-12520

BEARING

18

708-2J-05130

SPACER KIT

|$23

NSS

SPACER, T= 1.60 MM

|$24

NSS

SPACER, T= 1.70 MM

|$25

NSS

SPACER, T= 1.80 MM

|$26

NSS

SPACER, T= 1.90 MM

|$27

NSS

SPACER, T= 2.00 MM

|$28

NSS

SPACER, T= 2.10 MM

|$29

NSS

SPACER, T= 3.15 MM

|$30

NSS

SPACER, T= 3.65 MM

|$31

NSS

SPACER, T= 4.15 MM

19

04064-04018

RING, SNAP

20

708-2J-05120

SHIM KIT

|$34

NSS

SHIM, T= 0.10 MM

|$35

NSS

SHIM, T= 0.20 MM

|$36

NSS

SHIM, T= 0.50 MM

|$37

NSS

SHIM, T= 1.00 MM

21

04065-01030

RING

22

708-2J-13540

SPACER

23

01010-E1220

BOLT

24

708-2H-32350

WASHER

|$42

708-2J-05210

GEAR KIT

25

708-2J-13510

GEAR, BEVEL

26

708-2J-13520

PINION
