Запчасти Komatsu PC490LC-10 H-7A ГИДР. НАСОС. (7/7) ГИДРАВЛИКА

1

708-2J-12120

SHAFT, REAR

2

708-2J-12310

BEARING

3

708-2J-05110

WASHER KIT

|$4

NSS

WASHER, T = 2.8 MM

|$5

NSS

WASHER, T = 2.9 MM

|$6

NSS

WASHER, T = 3.0 MM

|$7

NSS

WASHER, T = 3.1 MM

|$8

NSS

WASHER, T = 3.2 MM

4

04064-06525

RING, SNAP, FOR SHAFT SIDE

5

708-2J-12160

SLEEVE

|$11

708-2J-04150

BLOCK ASSEMBLY, REAR

6

NSS

BLOCK, CYLINDER, REAR

7

NSS

PLATE, VALVE, REAR

8

708-18-13230

PIN

9

04065-06525

RING, SNAP

10

708-2J-13130

SEAT

11

708-2J-13150

SPRING

12

708-2J-13140

SEAT

13

708-2J-13350

GUIDE, RETAINER

14

708-2H-23360

PIN

15

708-2J-13340

RETAINER, SHOE

16

708-2J-13310

PISTON SUBASSEMBLY

|$23

708-2J-04160

CRADLE SUBASSEMBLY

17

NSS

CRADLE

18

NSS

CAM, ROCKER

19

04020-01434

PIN, DOWEL

20

01252-61235

BOLT
