Запчасти Komatsu PC490LC-10 H- ГИДР. БАК. ГИДРАВЛИКА
32
33
37
35
38
30
36
31
29
28
34
27
26
12
14
11
13
9
2
10
18
20
3
7
20
2
18
19
39
21
22
25
23
24
1
17
8
15
6
7
16
40
41
5
4
1
208-60-41113
TANK
2
203-60-31100
ELBOW ASSEMBLY
3
203-60-31160
TUBE
4
07044-12412
PLUG
5
07002-12434
O-RING
6
02782-10315
ELBOW
7
07002-12034
O-RING
8
02896-11009
O-RING
9
11Y-62-12440
NIPPLE
10
07002-12434
O-RING
11
02896-11018
O-RING
12
02782-10628
ELBOW
13
07002-62434
O-RING
14
02896-61018
O-RING
15
21W-62-42640
ELBOW
16
07002-13334
O-RING
17
207-62-64740
O-RING
18
02782-10422
ELBOW
19
07002-12034
O-RING
20
02896-11012
O-RING
21
07040-12012
PLUG
22
07002-12034
O-RING
23
02781-0031D
UNION
24
07002-11423
O-RING
25
02896-11009
O-RING
26
208-60-71123
ELEMENT
27
07069-25400
STRAINER
28
208-60-71160
VALVE ASSEMBLY
29
07069-34075
SPRING
30
208-60-71130
PLATE
31
07000-15210
O-RING
32
01010-81225
BOLT
33
01643-31232
WASHER
34
208-60-41121
STRAINER ASSEMBLY
35
208-60-61190
COVER
36
07000-15180
O-RING
37
01010-81225
BOLT
38
01643-31232
WASHER
39
208-54-43170
BRACKET
40
01010-81230
BOLT
41
01643-31232
WASHER
