Запчасти Komatsu PC490LC-10 LS ТРУБЫ (№8-) LS ТРУБЫ, С -СЕРВИСНЫЙ КЛАПАН

1

208-62-43481

Hose

2

208-62-43471

Hose

3

20Y-62-22790

Band, Red

4

20Y-62-22850

Band, Green

5

04435-51812

Clip

6

01010-81230

Bolt

7

01643-31232

Washer

8

208-62-41382

Hose

9

04434-51812

Clip

10

01010-81225

Bolt

11

01643-31232

Washer

12

208-62-41412

Hose

13

208-62-41970

Hose

14

208-62-41372

Hose

15

20Y-62-22830

Band, White

16

208-62-41282

Hose

17

20Y-62-22820

Band, Blue

18

04434-52312

Clip

19

01010-81225

Bolt

20

01643-31232

Washer

21

208-62-41980

Hose

22

20Y-62-22810

Band, Yellow

23

113-899-7950

Clip

24

01010-81225

Bolt

25

01643-31232

Washer

26

02782-10212

Elbow

27

02896-11008

O-ring

28

07002-11423

O-ring

29

20Y-62-87510

Tee

30

02896-11008

O-ring

31

02896-11009

O-ring

32

07002-11423

O-ring

33

04435-51812

Clip

34

20Y-62-13450

Plate

35

01010-81235

Bolt

36

01643-31232

Washer

37

08034-20536

Band
