Запчасти Komatsu PC490LC-10 ПОРШЕНЬ НАСОС, ВНУТР. ЧАСТИ (/7) (№8-) ПОРШЕНЬ НАСОС

Схема запчастей Komatsu PC490LC-10 - ПОРШЕНЬ НАСОС, ВНУТР. ЧАСТИ (/7) (№8-) ПОРШЕНЬ НАСОС
33
2
1
2
5
6
7
8
9
10
12
13
14
15
16
17
20
21
23
27
28
32
32
33
11
2
22
24
25
26
3
4
30
31
29
19
18

Артикул

Название

Примечание

Количество

|$0

708-2J-00010

Pump Assembly, Piston

|$1

708-1T-00580

Pump Assembly, Piston

|$2

708-1T-01581

Pump Subassembly

|$3

708-1T-04630

Case Assembly

1

Case, Pump

2

Plug

3

Sleeve

4

Ring

5

708-1T-13430

Cam, Rocker

6

04260-01270

Ball

7

708-3S-14141

Spacer

8

708-1S-13420

Pin

9

01252-60616

Bolt, Hexagon Socket Head

10

708-1T-33432

Ball, Retainer

11

708-1T-33470

Ball, Retainer

12

01252-61235

Bolt, Hexagon Socket Head

13

04020-01024

Pin, Dowel

14

708-1T-19270

Plate

15

07000-B2065

O-ring

16

01010-61025

Bolt

17

01643-31032

Washer

18

07040-11409

Plug

19

07002-61423

O-ring

|$23

708-1T-04641

Cap Subassembly

20

Cap, End

21

Plug

22

708-1S-12260

Bearing

23

720-68-19610

Pin

24

708-7T-05020

Spacer Kit

24

Spacer, T=1.6mm

24

Spacer, T=1.7mm

24

Spacer, T=1.8mm

24

Spacer, T=1.9mm

24

Spacer, T=2.0mm

24

Spacer, T=2.1mm

24

Spacer, T=2.2mm

25

708-1S-12280

Ring, Wear

26

708-1S-12330

Retainer

27

07000-B1006

O-ring

28

07000-B2130

O-ring

29

708-3T-11310

Orifice

30

708-2L-25480

Filter

31

708-2L-25490

O-ring

32

708-1L-25210

Plug

33

07002-61423

O-ring

Выбрано товаров: 45
