Запчасти Komatsu PC490LC-10 ПОРШЕНЬ НАСОС, ВНУТР. ЧАСТИ (8/7) (№8-) ПОРШЕНЬ НАСОС

|$0

708-2J-00010

Pump Assembly, Piston

|$1

708-2J-01010

Pump Subassembly

1

708-2J-14110

Slider

1

708-2J-03110

Valve Assembly, PC

1

708-2J-04170

Piston Assembly, Servo

2

Piston, Servo

3

Plug

4

708-2J-14130

Plug

5

708-2J-14140

Seal

6

708-2J-15110

Plug

7

708-2L-35760

Ball

8

708-2L-35770

Plug

9

708-2L-35690

Seal

10

708-2J-15120

Pin

11

708-3M-15670

Spool

12

708-2J-15130

Seat

13

708-2J-15140

Seat

14

708-2J-15150

Spring

15

708-2J-15160

Spring

16

708-2J-15180

Seat

17

708-2J-15170

Spring

18

708-2J-14250

Screw

19

07000-B3042

O-ring

20

708-2J-14230

Ring, Back-up

21

708-2J-14270

Seal

22

708-2J-15190

Plug

23

07000-B2014

O-ring

24

07000-B2055

O-ring

25

708-2J-14240

Ring, Back-up

26

708-2J-14210

Cover

27

01580-10806

Nut

28

708-2L-35290

Nut

29

708-2J-14260

Ring, Wear

30

708-2J-14150

Seal Ring

31

01010-61860

Bolt

32

01643-31845

Washer
