Запчасти Komatsu PC490LC-10 ВОЗДУХООЧИСТИТЕЛЬ, ВОЗДУХООЧИСТИТЕЛЬ КОМПОНЕНТЫ (/) (№8-) ВОЗДУХООЧИСТИТЕЛЬ

1

6751-81-5190

Joint

2

07206-30812

Bolt, Joint

3

07005-01212

Seal, Washer

4

01010-81070

Bolt

5

01643-31032

Washer

6

6252-21-7180

Hose

7

07281-00419

Clamp

8

6252-21-7630

Hose

9

07281-00419

Clamp

10

6252-21-7730

Hose

11

6252-21-7520

Hose

12

6252-21-7510

Hose

13

6252-21-7290

Gasket

14

6252-21-7280

Connector

15

600-051-2160

Clip

16

07281-00197

Clamp

17

01010-81030

Bolt

18

01643-31032

Washer

19

01010-81020

Bolt

20

01643-31032

Washer

21

7700-45-1710

Bolt, Joint

22

6261-51-2810

Valve, Check

23

6252-21-7470

Joint

24

6151-51-8490

Spacer

25

600-051-2160

Clip

26

07281-00197

Clamp

27

6252-21-7640

Hose

28

6252-21-7660

Hose

29

07005-01412

Seal, Washer

30

01010-81025

Bolt

31

01643-31032

Washer

32

6252-21-7710

Tube

33

01010-81030

Bolt

34

01643-31032

Washer

35

6252-11-2900

Sensor, Pressure

36

600-331-1930

Bolt

37

01640-20508

Washer

38

6252-21-7670

Hose

39

07281-00419

Clamp

40

6252-21-7720

Hose

41

07281-00197

Clamp

42

208-01-41173

Bracket

43

01010-81230

Bolt

44

01643-31232

Washer
