Запчасти Komatsu PC490-10 CAMERA (№K-UP) CAMERA

1

7835-33-2001

Camera

2

22U-06-31260

Cover

3

01010-81230

Bolt

4

01643-31232

Washer

5

22U-06-31430

Bracket

6

01010-80835

Bolt

7

01643-30823

Washer

8

20Y-810-1240

Cushion

9

22U-06-31440

Bracket

10

01010-80616

Bolt

11

01643-30623

Washer

12

01010-80616

Bolt

13

01643-30623

Washer

14

175-06-81610

Grommet

15

08059-00310

Clamp

16

207-06-76420

Cover

17

01010-80616

Bolt

18

01643-30623

Washer

19

207-06-76451

Cover

20

208-06-42220

Bracket

21

208-06-42260

Plate

22

01010-81225

Bolt

23

01643-31232

Washer

24

208-06-K4240

Cable

25

08034-20536

Band

26

04434-51012

Clip

27

04434-51012

Clip

28

01010-81225

Bolt

29

01643-31232

Washer

30

01010-81220

Bolt

31

01643-31232

Washer

32

198-43-15310

Collar

33

01010-81235

Bolt

34

01643-31232

Washer

35

175-61-17240

Spacer

36

01010-81285

Bolt

37

01643-31232

Washer

38

208-06-K4250

Cable

39

08034-20536

Band

40

08034-20536

Band

41

08034-20536

Band

42

08193-20012

Clip
