Запчасти Komatsu PC490-10 МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА, МОТОР ХОДА (/) МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

208-27-00321

Final Drive Assembly

|$1

706-8J-01030

Motor Assembly

1

706-8J-41110

Case, Motor

|$3

706-8J-00013

Cover Subassembly

2

Cover, End

2

Plate Assembly, Valve

3

Plate, Valve

4

Bushing

5

Cylinder Block

6

Spool

7

Plug

8

706-86-71310

Pin, Dowel

9

706-8E-14191

Plug

10

07002-11823

O-Ring

11

706-8J-71550

Piston

12

706-8J-71560

Pin

13

706-8J-71130

Plug

14

07002-12434

O-Ring

15

706-8J-71140

Plug

16

07002-12434

O-Ring

17

20B-27-11210

Bleeder

18

706-75-74540

Valve

19

706-75-74550

Spring

20

706-75-74850

Plug

21

07002-13334

O-Ring

22

708-8F-36120

Ring

23

706-78-71280

Spring

24

706-78-71230

Plug

25

07002-13634

O-Ring

26

706-8E-14170

Spring

27

706-8J-71150

Spool

28

706-8J-71160

Plug

29

07002-11823

O-Ring

30

706-86-53410

Valve

31

706-8J-71170

Plug

32

07002-11023

O-Ring

33

708-8E-16180

Valve

34

706-8J-71181

Valve

35

708-8E-16160

Plug

36

07002-11023

O-Ring

37

706-8J-71190

Plug

38

07002-11223

O-Ring

39

07000-15275

O-Ring

40

07000-12012

O-Ring

41

01252-62060

Bolt
