Запчасти Komatsu PC490-10 ОСНОВН. ПОРШЕНЬ НАСОС, ВНУТР. ЧАСТИ (/7) ОСНОВН. ПОРШЕНЬ НАСОС

|$0

708-2J-00010

Pump Assembly, Piston

|$1

708-2J-01010

Pump Subassembly

1

708-2J-12150

Coupling

2

708-2J-13530

Bearing, Thrust

3

708-2H-32320

Bushing

4

708-2J-13360

Impeller

5

01010-E1220

Bolt

6

708-2H-32350

Washer

7

708-2H-32360

Shaft

8

708-2J-11140

Cover

9

07000-A2105

O-Ring

10

708-2H-05120

Shim Kit

10

Shim, T=0.1mm

10

Shim, T=0.2mm

10

Shim, T=0.5mm

11

01010-81235

Bolt

12

01643-31232

Washer

|$17

708-2J-04210

Case Assembly

13

708-2J-12530

Case

14

708-2J-12540

Collar

15

708-2J-12510

Shaft

16

708-8H-22350

Bearing

17

708-2J-12520

Bearing

18

708-2J-05130

Spacer Kit

18

Spacer, T=1.6mm

18

Spacer, T=1.7mm

18

Spacer, T=1.8mm

18

Spacer, T=1.9mm

18

Spacer, T=2.0mm

18

Spacer, T=2.1mm

18

Spacer, T=3.15mm

18

Spacer, T=3.65mm

18

Spacer, T=4.15mm

19

04064-04018

Ring, Snap

20

708-2J-05120

Shim Kit

20

Shim, T=0.1mm

20

Shim, T=0.2mm

20

Shim, T=0.5mm

20

Shim, T=1.0mm

21

04065-01030

Ring

22

708-2J-13540

Spacer

23

01010-E1220

Bolt

24

708-2H-32350

Washer

|$43

708-2J-05210

Gear Kit

25

708-2J-13510

Gear, Bevel

26

708-2J-13520

Pinion
