Запчасти Komatsu PC460LC-8 ДЕМПФЕР И ПОРШЕНЬ НАСОС (ВНУТР. ЧАСТИ) (/) B [КОМПОНЕНТЫ ДВИГАТЕЛЯ]

|$1

708-2H-00451

PUMP ASSEMBLY

|$2

708-2H-01451

PUMP SUBASSEMBLY

1

708-2H-32110

SHAFT

2

708-1H-22150

BEARING

3

708-17-05010

WASHER KIT

|$6

WASHER, T=3.0MM

|$7

WASHER, T=3.1MM

|$8

WASHER, T=3.2MM

4

708-17-12780

RING, SNAP

5

708-2H-22570

SEAL, OIL

6

708-2H-22160

SPACER

7

04065-08225

RING, SNAP

|$13

708-2H-04750

CYLINDER BLOCK ASSEMBLY

8

BLOCK, CYLINDER

9

PLATE, VALVE, VALVE

10

708-18-13230

PIN

11

04065-05820

RING, SNAP

12

708-2H-33140

SEAT

13

708-2H-33150

SPRING

14

708-2H-23141

SEAT

15

708-2H-23350

GUIDE, RETAINER

16

708-2H-23360

PIN

17

708-2H-33343

RETAINER, SHOE

18

708-2H-33311

PISTON SUBASSEMBLY

|$25

708-2H-04690

CRADLE SUBASSEMBLY

19

CRADLE

20

CAM, ROCKER

21

04020-01434

PIN, DOWEL

22

07000-B1009

O-RING

23

01252-61235

BOLT, HEXAGON SOCKET HEAD
