Запчасти Komatsu PC460LC-8 МЕХАНИЗМ ПОВОРОТА И МОТОР N [ПОВОРОТН. КРУГ И ITS КОМПОНЕНТЫ]

1

207-26-71240

RING

2

07040-11209

PLUG

3

07002-11223

O-RING

4

208-26-71190

CASE

5

07049-02430

PLUG

6

208-26-71530

BEARING

7

208-26-71540

BEARING

8

208-26-52242

SHAFT

9

208-26-61290

SEAL, OIL

10

21N-26-33230

COVER

11

01010-81030

BOLT

12

01643-31032

WASHER

13

07000-15390

O-RING

14

208-26-71181

CARRIER

15

208-26-71140

GEAR

16

207-27-61390

BEARING

17

20Y-27-21250

WASHER

18

207-27-61250

PIN

19

20Y-27-21290

PIN

20

208-26-71230

PLATE

21

205-32-51211

BOLT

22

208-26-71150

GEAR

23

01010-81645

BOLT

24

01643-31645

WASHER

25

208-26-71130

GEAR

26

208-26-71241

PLATE

27

208-26-71170

CARRIER

28

207-26-71521

GEAR

29

22U-26-21320

BEARING

30

22U-26-21240

WASHER

31

207-26-71210

PIN

32

04064-04018

RING, SNAP

33

208-26-71210

HOLDER

34

04260-01270

BALL

35

207-26-71511

GEAR

36

207-26-71261

PLATE

37

144-60-11151

VALVE

38

07270-21590

TUBE

39

07281-00197

CLAMP

40

01010-81240

BOLT
