Запчасти Komatsu PC45R-8 МАРКИРОВКА (НАВЕС) МАРКИРОВКА

Схема запчастей Komatsu PC45R-8 - МАРКИРОВКА (НАВЕС) МАРКИРОВКА
9
2
6
31
17
8
31
2
18
21
25
30
1
10
9
32
19
4
24
20
9
28
1
3
8
7
2
16
10
9
e
e
a
b
c
d
e
f
26
23
22
14
a
13
12
b
c
11
29
5
14
15
27
f
d

Артикул

Название

Примечание

Количество

\0

816200011

MARK PLATE KIT

1

3F45B2649

MARK PLATE, PC45R

2

333314657

MARK PLATE, KOMATSU

3

312614616

MARK PLATE, UTILITY

4

3F45B2625

MARK PLATE, OPERATING, RAISING CAPACITY

5

3F10B2638

MARK PLATE, MARK, SOUND PRESSURE LEVEL ®LPA 80Ї

6

3F10B2642

MARK PLATE, MARK, SOUND POWER LEVEL ®LWA 98Ї

\6

816214659

KIT, MARK PLATE

7

3F10B2645

PLATE, CONTROLS LEVER, BOOM SWING, ATTACHMENT

8

3F05B2612

PLATE, SAFETY, KEEP OUT TURNING AREA

9

3F05B2608

PLATE, LIFTING POINT

10

3F10B2608

MARK PLATE, ANCHOR POINTS

11

3F10B2606

PLATE, SAFETY, ELECTRIC SOCKET

12

3F30B2603

PLATE, OPERATING, TRAVEL SPEED

13

816212382

PLATE, OPERATING SWING LOCK LEVER

14

3F10B2602

PLATE, OPERATING, CONTROL LOCK

15

3F10B2644

PLATE, OPERATING, ATTACHMENT

16

3F10B2605

PLATE, SAFETY, HYDRAULIC OIL FILTER

17

3F05B2622

PLATE, SAFETY, HYDRAULIC OIL

18

3F10B2604

PLATE, SAFETY, HYDRAULIC OIL LEVEL

19

3F10B2612

PLATE, OPERATING BLADE

20

3F10B2613

PLATE, OPERATING, FUEL CONTROL

21

3F30B2602

PLATE, SAFETY, DO NOT STATION IN THE WORK AREA

22

3F30B2608

PLATE, SAFETY, GREASE

23

3F45B2622

PLATE, LUBRICATING POINT

24

3F05B2623

PLATE, SAFETY, FUEL

25

3F05B2627

PLATE, SAFETY FUEL FILTER

26

3F05B2628

PLATE, SAFETY, ENGINE AIR FILTER

27

3F05B2626

PLATE, SAFETY, ENGINE OIL FILTER

28

3F05B2633

PLATE, SAFETY, RADIATOR CAP

29

3F05B2609

PLATE, READ MANUAL

30

3F05B2607

PLATE, SAFETY, DO NOT OPEN ENGINE HOOD

31

3F05B2672

MARK PLATE, REFLEX REFLECTOR

32

3F45B2624

ANTISLIP

Выбрано товаров: 34
