Запчасти Komatsu PC45R-8 ГЕНЕРАТОР ДВИГАТЕЛЬ

Схема запчастей Komatsu PC45R-8 - ГЕНЕРАТОР ДВИГАТЕЛЬ
34
1
35
31
2
32
33
30
4
7
6
5
11
10
8
9
12
24
29
15
16
3
27
28
19
21
20
22
14
23
25
17
18
26
13
A
B

Артикул

Название

Примечание

Количество

\0

871070070

ENGINE, ASSY.

1

YM119940-77330

ADJUSTER, BELT

2

YM129423-77200

ALTERNATOR, ASSY.

3

YMX9490561001

NUT

4

YM119620-77380

ROTOR,ASSY.

5

YM119620-79240

BEARING

6

YM119620-79250

RING

7

YM119620-79360

WASHER

8

YM119620-77421

COIL ASSY.,FIELD

9

YM119620-79200

BEARING

10

YM119620-79210

PLATE

11

YM119620-79220

SCREW

12

YM119620-79230

STUD

13

YM119620-77440

STATOR

14

YM129423-77450

COVER

15

YM119620-77461

PULLEY

16

YM119620-77471

NUT

17

YM129423-77710

GOVERNOR

18

YM119620-79260

COVER

19

YM119620-79270

HOLDER BRUSH, ASSY.

20

YM119620-77480

FLEX HORN

21

YM119620-79280

SPRING

22

YM119620-79290

SCREW

23

YM119620-79300

SCREW

24

YM119620-79310

BOLT

25

YM119620-79320

SCREW WASHER

26

YM119620-79330

BOLT

27

YM119620-79340

INSULATING

28

YM119620-79350

NUT

29

YM119620-77490

COLLAR

30

YM119620-79360

WASHER

31

YM129795-01900

STUD

32

YM26306-100002

NUT

33

YM26106-080452

BOLT

34

YM119940-77270

ADJUSTER, BELT

35

YM26014-080352

SCREW

Выбрано товаров: 36
