Запчасти Komatsu PC45R-8 ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC45R-8 - ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ
37
50
53
51
43
52
45
49
41
44
42
26
48
54
38
37
40
36
40
33
34
40
36
27
47
33
34
36
1
34
33
29
40
36
39
33
34
36
29
40
28
33
34
36
30
39
33
34
36
28
29
34
33
36
39
33
34
38
28
29
22
20
40
25
17
40
4
16
23
27
24
15
11
18
19
7
9
2
5
3
12
21
14
13

Артикул

Название

Примечание

Количество

\0

871070024

MOTOR, ASSY.

1

YM23065-160800

PIPE

2

YM124736-07900

LIFTER

3

YM26106-080142

BOLT

4

YM129407-11700

HEAD,ASSY.

5

HEAD, ASSY.

7

YM120130-11860

GUIDE VALVE

9

YM129150-11810

GUIDE VALVE

11

YM26216-060202

STUD

12

YM27241-400000

PLUG

13

YM129100-11100

VALVE, INLET

14

YM129100-11110

VALVE EXHAUST

15

YM129795-11120

SPRING, VALVE

16

YM129795-11180

RETAINER, SPRING

17

YM27310-080000

COTTER

18

YM121400-11340

SEAL, VALVE EXHAUST

19

YM124460-11340

SEAL, VALVE STEM

20

YM129150-11370

CAP VALVE

21

YM22351-060012

PEG

22

YM26366-060002

NUT

23

YM119625-11870

PROTECTION, NOZZLE

24

YM119625-11880

SEAT, NOZZLE

25

YM119625-11900

RETAINER

26

YM129555-11241

SHAFT

27

YM129155-11260

SUPPORT

28

YM129155-11270

SUPPORT

29

YM129150-11280

SPRING

30

YM129550-11290

SHAFT

33

YM729402-11650

ROCKER SHAFT

34

YM129150-11230

SCREW

36

YM129150-11750

NUT

37

YM26226-080182

STUD

38

YM26756-080002

NUT

39

YM26106-080252

SCREW

40

YM26106-080502

SCREW

41

YM129400-11350

COVER

42

YM124160-01751

PLUG

43

YM129150-03020

COVER, BREATHER

44

YM129150-03070

SPLASH-GUARD

45

YM129150-03080

PROTECTION

47

YM129550-11310

GASKET

48

YM24311-000320

O-RING

49

YM24341-000500

O-RING

50

YM26106-080162

BOLT

51

YM124160-11360

PLUG

52

YM24311-000120

O-RING

53

YM198220-51870

CLAMP

54

YM121750-59890

RETAINER

Выбрано товаров: 48
