Запчасти Komatsu PC45R-8 РЕГУЛЯТОР ДВИГАТЕЛЬ

Схема запчастей Komatsu PC45R-8 - РЕГУЛЯТОР ДВИГАТЕЛЬ
80
A
C
B
61
B
A
C
A
72
A
69
79
61
106
65
56
22
5
6
57
64
15
60
67
68
59
70
82
75
78
18
81
71
76
4
23
66
55
31
45
58
7
30
24
63
77
31
63
10
24
14
29
72
73
62
2
74

Артикул

Название

Примечание

Количество

\0

871070024

MOTOR, ASSY.

\0

YM729613-51380

PUMP, ASSY.

\0

REGULATOR, ASSY.

2

YM129155-51280

O-RING

4

YM129052-61050

GASKET

5

YM129052-61060

COVER

6

YM129052-61070

GASKET

7

YM129155-61120

LINK L=30 (0)

7

YM129155-61130

LINK L=31 (1)

7

YM129155-61140

LINK L=30.5 (0.5)

10

YM129155-61201

WEIGHT ASSY., GOVERNOR

14

YM129155-61341

SLEEVE

15

YM129100-61400

SHAFT, CONTROL

18

YM129155-61430

SPACER

22

YM129155-61450

BOLT, REVOL. LIMIT

23

YM129155-61460

BOLT, IDLE LIMIT

24

YM129155-61480

SPACER

29

YM129052-61390

SHAFT, GOVERNOR LEVER

30

YM129052-61500

TORQUE SPRING ASSY.

31

YM174307-51700

KIT, SHIM

45

YM129052-61540

SPRING

55

YM119660-61901

RETAINER, SHAFT

56

YM129155-61950

SCREW

57

YM124550-66370

NUT

58

YM22117-040000

WASHER

59

YM22190-060002

SPRING WASHER

60

YM22190-100002

GASKET

61

YM22190-120002

WASHER

62

YM22287-120000

WASHER

63

YM22372-040000

PIN

64

YM23887-100002

PLUG

65

YM24341-000280

O-RING

66

YM26106-060102

BOLT PLATED

67

YM26106-060102

BOLT PLATED

68

YM26106-060102

BOLT PLATED

69

YM26106-060142

BOLT

70

YM26106-060202

BOLT

71

YM26756-060002

NUT

72

YM26776-120002

NUT

73

YM129155-61350

SLEEVE

74

YM129155-61360

SLEEVE

75

YM129155-61830

O-RING

76

YM129100-61440

HANDLE

77

YM129100-61650

SPRING

78

YM171353-61710

SPRING

79

YM119233-77931

COIL

80

YM26687-120002

CAP NUT

81

YM26366-080002

NUT

82

YM171353-61550

ANGLEICH ASSY.

106

YM129155-61470

SCREW

Выбрано товаров: 50
