Запчасти Komatsu PC45R-8 ГЕНЕРАТОР ДВИГАТЕЛЬ

Схема запчастей Komatsu PC45R-8 - ГЕНЕРАТОР ДВИГАТЕЛЬ
26
27
25
24
28
1
23
22
4
3
21
2
19
20
18
17
16
7
14
15
6
8
11
5
13
12
9
10

Артикул

Название

Примечание

Количество

\0

871070047

ENGINE, ASSY.

1

YM119836-77200

GENERATOR

1

YM119836-77201

GENERATOR

2

YM119836-77700

ROTOR,ASSY.

3

YM119836-77850

BEARING

4

YM119836-77710

COIL ASSY.,FIELD

5

YM119836-77721

COVER, REAR, ASSY.

6

YM119836-77730

COVER, REAR, ASSY.

7

YM119836-77741

BRUSH ASSY., REGULATOR

8

YM119836-77750

FLEX HORN

9

YM119836-77760

GUIDE

10

YM119836-77770

DIODE ASSY.

11

YM119836-77780

CONDENSER

12

YM119836-77871

SCREW

13

YM119836-77880

SCREW

14

YM119836-77890

CABLE, ASSY.

15

YM119836-77790

COVER ASSY., FRONT

16

YM119836-77800

RETAINER

17

YM119836-77840

BEARING

18

YM119836-77860

KIT, SCREW

19

YM119836-77810

PULLEY

20

YM119836-77820

NUT ASSY., PULLEY

21

YM119836-77830

KIT, SCREW

22

YM129136-77251

SCREW

23

YM119820-77340

SPACER

24

YM129612-77260

NUT

25

YM129612-77300

ADJUSTER, BELT

26

YM119810-77340

SCREW

27

YM106500-44810

SPACER

28

YM26106-080502

SCREW

Выбрано товаров: 30
