Запчасти Komatsu PC45R-8 ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

\0

871070047

ENGINE, ASSY.

1

YM23065-160800

PIPE

2

YM124736-07900

LIFTER

3

YM26106-080142

BOLT

4

YM129407-11700

HEAD,ASSY.

5

HEAD, ASSY.

7

YM120130-11860

GUIDE VALVE

9

YM129150-11810

GUIDE VALVE

11

YM26216-060202

STUD

12

YM27241-400000

PLUG

13

YM129100-11100

VALVE, INLET

14

YM129100-11110

VALVE EXHAUST

15

YM129795-11120

SPRING, VALVE

16

YM129795-11180

RETAINER, SPRING

17

YM27310-080000

COTTER

18

YM121400-11340

SEAL, VALVE EXHAUST

19

YM124460-11340

SEAL, VALVE STEM

20

YM129150-11370

CAP VALVE

21

YM22351-060012

PEG

22

YM26366-060002

NUT

23

YM119625-11870

PROTECTION, NOZZLE

24

YM119625-11880

SEAT, NOZZLE

25

YM119625-11900

RETAINER

26

YM129555-11241

SHAFT

27

YM129155-11260

SUPPORT

28

YM129155-11270

SUPPORT

29

YM129150-11280

SPRING

30

YM129550-11290

SHAFT

33

YM729402-11650

ROCKER SHAFT

34

YM129150-11230

SCREW

36

YM129150-11750

NUT

37

YM26226-080182

STUD

38

YM26756-080002

NUT

39

YM26106-080252

SCREW

40

YM26106-080502

SCREW

41

YM129400-11350

COVER

42

YM124160-01751

PLUG

43

YM129150-03020

COVER, BREATHER

44

YM129150-03070

SPLASH-GUARD

45

YM129150-03080

PROTECTION

47

YM129550-11310

GASKET

48

YM24311-000320

O-RING

49

YM24341-000500

O-RING

50

YM26106-080162

BOLT

51

YM124160-11360

PLUG

52

YM24311-000120

O-RING

53

YM198220-51870

CLAMP

54

YM121750-59890

RETAINER
