Запчасти Komatsu PC45R-8 МОТОР ХОДА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

20T-60-82121

TRAVEL MOTOR ASS'Y

|1

20T-60-82120

TRAVEL MOTOR ASS'Y

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1651-01A0 TO Y1651-03A0.

|1

TZ599B1000-00

FINAL DRIVE ASS'Y

|1

TZ573B1000-03

FINAL DRIVE ASS'Y

1

TZ596B1001-00

HUB

|1

TZ573B1001-00

HUB

|2

TZ599B1102-00

SPINDLE

|2

TZ573B1102-03

SPINDLE KIT

2

TZ599B1132-00

SPINDLE ASS'Y

|2

TZ573B1132-03

SPINDLE ASS'Y

3

TZ550A1019-00

BOLT,REAMER

|4

TZ573B1104-02

RV GEAR ASS'Y

4

TZ573B1204-02

RV GEAR KIT

5

TZ573B1009-00

SHAFT,CRANK

6

TZ310B1022-01

BEARING

7

TZ850A1023-00

BEARING,NEEDLE

8

TZ573B1006-00

GEAR,INPUT

9

TZ573B1107-00

SPUR GEAR KIT (3 PIECES)

10

TZ510B1008-01

COVER

11

TZ573A1014-00

PIECE,DISTANCE

12

TZ573B1017-00

PIN

13

TZ550A1018-00

RING

14

TZ310B1013-00

SNAP RING KIT (12 KINDS)

15

TZ573B1021-00

BEARING

16

04064-01510

RING,SNAP

17

04064-02212

RING,SNAP

18

07000-11007

O-RING (K1)

19

07000-05200

O-RING (K1)

20

TZJW1516-G26-7

O-RING (K1)

21

TZES100-178-B

SEAL,FLOATING (K1)

22

TZGM3-8

PLUG

|$$33

SERVICE KIT

K-1

TZ573B9000-00

SERVICE KIT

|K

07000-11007

O-RING

|K

07000-05200

O-RING

|K

TZJW1516-G26-7

O-RING

|K

TZES100-178-B

SEAL,FLOATING

|K

TZ15Z-17-35-8

SEAL,OIL

|K

TZ571B2035-01

O-RING

|K

TZJB2401-P22-9

O-RING

|K

07000-12012

O-RING

|K

TZ571B2039-01

O-RING

|K

TZ571B2078-01

O-RING
