Запчасти Komatsu PC45R-8 МОТОР ХОДА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

20T-60-82121

TRAVEL MOTOR ASS'Y

|1

20T-60-82120

TRAVEL MOTOR ASS'Y

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1651-01A0 TO Y1651-03A0.

|1

TZ596B200001EA

HYDRAULIC MOTOR A.

|1

TZ573B200001EA

HYDRAULIC MOTOR A.

|$$6

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1651-01A0 AND Y1651-02A0.

|1

TZ569B210001-A

HOUSING

|1

TZ573B210001-A

FLANGE ASS'Y,REAR

1

TZ596B210101-A

FLANGE

|1

TZ573B210101-A

FLANGE KIT,REAR

2

TZGM1-8

PLUG

3

TZS0605

ORIFICE

4

TZ571B2079-00

PLUG

5

TZ263B2079-01

FILTER

6

TZ850A0006-00

PLATE¤ NAME

7

TZ312A2018-00

SEAT,VALVE

8

TZ571B2019-02

VALVE

9

TZ312A2020-00

SPRING

10

TZGM-1/4-K

PLUG

11

TZ312A2022-00

RING

12

TZ571B2051-01

PLUG

13

TZ300A2053-00

PLUG

14

TZ300A2054-00

VALVE

15

TZ571B2066-00

SPRING

16

TZ300A2055-00

SPRING

17

07000-11007

O-RING (K1)

18

TZJB2401-P22-9

O-RING (K1)

19

07000-12012

O-RING (K1)

20

TZ200B2073-00

VALVE

21

TZ300B2039-00

STOPPER

22

TZ300B2042-00

RING

23

TZ300B2043-01

SPRING

24

04260-00476

BALL
