Запчасти Komatsu PC45R-8 РУКОЯТЬ (ДЛЯ QUICK ГИДРОМОЛОТ) (РУКОЯТЬ¤НАВЕСН.ОБОРУД. ЛИНИЯ¤ПАЛЕЦ) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

20T-870-0010

ARM ASS'Y

1

ARM,FIRST

2

20T-70-81250

BUSHING

3

07145-00050

SEAL,DUST

4

07020-00000

FITTING,GREASE

5

201-70-64270

BUSHING

6

07145-00050

SEAL,DUST

7

07020-00000

FITTING,GREASE

8

20T-870-1611

ARM,SECOND

9

20B-910-3210

PIN

10

20R-70-11250

PLATE

11

01010-81230

BOLT

12

01643-31232

WASHER

13

20T-70-81750

SPACER¤ 0.5MM

|13

424-46-12540

SHIM¤ 0.5MM

14

20T-870-1150

PIN

15

20T-870-1190

PIN,RING

16

20T-870-1250

HOSE

17

08037-05022

GROMMET

18

203-62-58650

COVER

19

08034-00519

BAND

20

20S-70-71571

PIN

21

04082-00212

LOCK

22

01010-81230

BOLT

23

01643-31232

WASHER

24

20T-70-81780

SPACER¤ 1.0MM

|24

20T-70-19130

SPACER¤ 1.0MM

25

20S-70-71571

PIN

26

04082-00212

LOCK

27

01010-81230

BOLT

28

01643-31232

WASHER

29

20T-70-81710

SPACER¤ 1.0MM

|29

20T-70-19130

SPACER¤ 1.0MM

30

20T-970-7231

COLLAR

31

20T-970-7241

COLLAR

32

20T-970-7480

BOLT

33

01643-33080

WASHER

34

01580-13024

NUT

35

20T-970-7330

SHIM¤ 0.5MM

36

20T-970-7340

COVER

37

20T-63-X2524

CYLINDER GROUP,BUCKET
