Запчасти Komatsu PC45R-8 КАБИНА (КОРПУС) (/7) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$3

20T-54-00800

OPERATOR'S CAB ASS'Y

|$4

20T-54-00850

OPERATOR'S CAB ASS'Y

|$5

20T-54-00860

OPERATOR'S CAB ASS'Y

1

20U-54-24671

BRACKET

2

01010-80816

BOLT

3

01643-30823

WASHER

4

205-54-63310

LOCK ASS'Y

5

01010-80816

BOLT

6

01643-30823

WASHER

7

20T-54-84620

STOPPER

7

20T-54-74311

STOPPER

8

20T-54-84630

STOPPER

8

20T-54-74331

STOPPER

9

20Y-54-14280

SCREW

10

205-54-71560

TRIM

11

20T-54-84650

SEAL,FRONT

12

01641-21016

WASHER

13

20T-54-84590

GLASS,LOWER

14

20U-54-24611

LATCH,L.H.

15

20U-54-24621

LATCH,R.H.

16

20T-54-32780

PACKING

17

20T-54-32870

PACKING, 1.0MM

18

20T-54-32750

PACKING, 2.0MM

19

20T-54-32760

RETAINER,L.H.

20

20T-54-32770

RETAINER,R.H.

21

01220-40512

SCREW

22

01601-20513

WASHER,SPRING

23

20T-54-84791

GLASS,REAR, UPPER

24

20U-54-24991

DAM

25

20T-54-84810

WIRING

26

21W-54-14691

CLIP,(NOT SHOWN) (FOR STD CAB)

26

21W-54-14691

CLIP

27

205-54-51250

HANGER

28

01225-70412

SCREW

29

20U-54-25570

CAP

30

20U-54-25180

COVER

31

01220-70612

SCREW

32

01643-70623

WASHER

33

20T-54-84950

COVER

34

01580-10605

NUT

35

01643-30623

WASHER

36

20T-54-84990

INSULATOR,REAR
